WT-FP90 Flat Solar Collector
Product classification：
WT-FP90 Flat Solar Collector MODEL WT-FP90-1 Copper Header Pipes(mm) Ф22*1.0
Copper Riser Tubes(mm) Ф10*0.7 No. Of Riser Tubes 8 Absorber structure, copper full-surface absorber
Spectrum Absorber Coating blue titanium coating (Tinox) Abso
Toll Free Tel:+400-820-8525
Product Description
WT-FP90 Flat Solar Collector
Panel Details:
* Panel: Ultrasonic welded selective surface coated copper plate
* Glaze: Low iron, temperate glass with 91% transmission
* Sealing: Enclosure seals are UV durable EPDM materials. Glazing gaskets are
one piece channel type with moulded comers to assure along life and avoids water penetration
* Case: Collector cases are aluminum coated with electrostatic black
color
* Insulation: CE Certified High Density Rockwool
* Flexible Connection: For ease of installation
* Back Sealing: Provided by clamps and silicone
* Air Ventilation Holes: Prevent intemal condensation
* Back Plate: Galvanized steel
* Wall Insulation: Special matt black painted glass wool for increased
performance
Technical Data:
|
MODEL |
WT-FP90-1 |
|
Copper Header Pipes(mm) |
Ф22*1.0 |
|
Copper Riser Tubes(mm) |
Ф10*0.7 |
|
No. Of Riser Tubes |
8 |
|
Absorber |
structure, copper full-surface absorber |
|
Spectrum Absorber Coating |
blue titanium coating (Tinox) |
|
Absorption Rate of Absorber |
95%±2% |
|
Emissivity of Absorber |
4%±1% |
|
Welding Between Absorber And Tubes |
ultrasonic welding |
|
Insulation Material |
rock wool |
|
Collector Mounting |
flat roof/pitched roof/balcony |
|
Cover Glass |
low iron textured tempered glass |
|
Glass Transmittance |
>91% |
|
Cover Thickness |
3.2mm |
|
Matched Water(l) |
100L-150L |
|
Water Temperature In Sun Day |
50-90 centigrade degree |
|
Highest Working Temperature |
170 centigrade degree |
|
Working Pressure |
0.6MPa |
|
Testing Pressure |
1.2MPa, keeping 15 minutes |
|
Gross Area |
2㎡ |
|
Aperture Area |
1.80㎡ |
|
Heat Transfer Fluid |
pure water and other heat transfer fluid |
|
Fluid Volume(l) |
1.5L |
|
Back Sheet |
galvanized plate |
|
Sealing Material |
EPDM |
|
Net Weight(kg) |
43.5 |
|
Gross Weight(kg) |
44 |
|
Unit Price |
USD 233 FOB Shanghai |
The TitanPower-ALDH29 premium flat plate
collector is the latest in flat plate technology. This collector is a step ahead with all-new mounting hardware.
Combining advanced technologies and manufacturing processes from around the world, the TitanPower-ALDH29 is able
to offer cutting-edge performance and premium quality with highly competitive pricing.
The
TitanPower-ALDH29 premium flat plate collector is the latest in flat plate technology. This collector is a step
ahead with all-new mounting hardware. Combining advanced technologies and manufacturing processes from around
the world, the TitanPower-ALDH29 is able to offer cutting-edge performance and premium quality with highly
competitive pricing.
